High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 1

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 2

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 3

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 4

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 5

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 6

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine 7

High Quality Automatic Film 3 Side Sealing Bag Making Machine Food Bags Zipper Making Machine Packaging Bags Making Machine

Model ：P-HX-500

MOQ ：1

Delivery time：30-60 days

Start Port ：Guangzhou,Ningbo,Shenzhen ect,.

Certification ：CE,IOS,RUSH ect,.

Brand：Prince

Factory Price：Negotiate

Supply Ability：1000 Set/Sets per Month

Payment Terms：L/C, Cash,T/T,Western Union ,Trade Assurance, Paypal

ODM & OEM：Available

Inquiry

Write a Review

Product parameters

Product Specification

Other attributes

Model	OR-HX500
Machine functions	Triple sided seal, zipper, automatically standing up
Applicable materials	BOPP, COPP, PET, nylon and other plastic composite films, multi-layer co extruded films, aluminum plated composite films, paper plastic composite films, pure aluminum foil composite films
Speed	Max.150pcs/min
Maximum discharge line speed	≤38 meters/minute (depending on the material)
Bag size	Length: 400mm, exceeding this length can be achieved by double feeding(Up to 6x delivery) Maximum width: 500mm
Max. size of material roll	φ 5001250 mm (DiameterWidth)
Positioning accuracy	≤±0.5mm
Temperature setting range	0~300℃
Overall power	65Kw (the actual power is usually around 45Kw when the machine is just powered on, and around 35Kw when it is insulated)
Weight	7500kg

Video outgoing-nspection	Provided	Machinery Test Report	Provided
Marketing Type	Ordinary Product	Warranty of core components	1 years
Marking Type	Hot Product 2022	Place of Origin	Henan, China
Weight	1200 KG	Machinery Test Report	Provided
Key Selling Points	High-accuracy	Condition	New
Automatic Grade	Automatic	Brand Name	PRINCE
Voltage	380V	*Dimension(LWH)*	92.61.55mm
Product name	Packaging Bags Making Machine	Name	Food Bags Zipper Making Machine
Keywords	3 Side Zipper Pouch Bag Making Machine	Feature	High Eifficiency
Application	Packaging Industry	Sultable material	Plastic Material
Type of bag	food bags	Speed	150PCS/min
Automatic	Full-automatic	Color	white

Product Description

This 3 Sides Sealing Zipper Doypack Pouch Bag Making Machine is well-processed and assembled, beautiful in appearance and reasonable in structure. The whole machine runs smoothly, low noise, easy zipper adjustment, accurate upright pouch punching, and fast running speed. PLC three-servo traction control is adopted, and the temperature computer is centrally controlled, which reduces electricity consumption. The main discharge and double vertical insert bottom discharge adopt constant tension control, which ensures the smoothness of the pulling material and the accuracy of the vertical punch control. The intermediate tension floating roller adopts dynamic compensation mode, so that the fluctuation up and down in the process of pulling material is minimal, and the intermediate tension control is stable.

more feature

1. This small plastic making bag machine has excellent processing and assembly, beautiful appearance and reasonable structure. This zipper bag making machine has horizontal sealing and colorless upright bag with curved bottom hot knife indentation overlap and good stability.

2.This small plastic making bag machine runs smoothly with low noise, convenient zipper adjustment, accurate punching of upright bags, and fast operation speed.

3. Adopting PLC three servo traction control and temperature computer centralized control, reducing power consumption.

4. The main discharge and double vertical insertion bottom discharge adopt constant tension control,ensuring the smoothness of material pulling and the accuracy of vertical punching control.

5. The middle tension floating roller adopts a dynamic compensation mode, which minimizes the fluctuation of up and down during the material pulling process, and the middle tension control is stable.

More Details

Stand up Pouch Making Machine (9)

Stand up Pouch Making Machine (3)

Product Show

QSK840精装书壳机详情 (3)

Stand up Pouch Making Machine (4)

Applicable
