Professional Straight-Line EVA Glue Binding Machine S10E S20E

The Digital Straight-Line EVA Glue Binding Machine (S-Series) delivers professional-grade perfect binding at 300+ books/hour for printing shops and publishers.

    oops...!

    no product data.

    Go to homepage
    Product Name
    Digital EAV Glue Binding Machine
    Machine Dimension
    2180*800*1085mm
    Model NO.
    S10E/S20E
    Weight
    320kg

    Product Description

    Glue Binding Machine has Fida CNC feeding, double drive CNC clamping surface, gluing thickness up to 58mm, with suction nozzle type automatic paper feeding function, can automatically identify, automatic creasing.


    Automated Setup: Input book dimensions via the 7-inch touchscreen, and the machine self-adjusts clamps, glue pressure, and milling depth in seconds

    Straight-Line EVA Glue Binding Machine

    Product Feature

    glue binding workflow
    1.CNC-controlled lifting and dropping of the book, stable, convenient and efficient

    2.CNC automatic creasing to improve the quality of the binding

    3.Book Binding Machine Glue With four-way secondary positioning, CNC lifting and stacking book

    4.Feeder: CNC air suction paper feeding structure design, synchronous completion of paper feeding and creasing, saving time, space, and reducing requirements for cover material.

    5.CNC side rail, automatic adjustment of creasing width: according to the binding thickness, thedistance between the creasing rollers is automatically adjusted, and the creasing roller does notget stuck,making the operation convenient.

    6.Double sheet separation: The double sheet separation technology quickly shakes the paperreducing the double sheet feeding caused by static electricity, ensuring smooth and efficientfeeding
    👉 Contact us today for a quote, product demo, or technical details!

    Product Details

    Hd8400b3a1fc34771b09aa2d1a723499aE
    Smoke extractor
    Extractor starts working auto when exceeding 120 degrees
    主图_005 (9)
    Micro adjustment of spine grinding roller
    Easy to control spine gluing thickness and side gluing
    glue binding machine (1)
    All in 7* Touchscreen
    All in 7* Touchscreen
    glue binder (8)
    Glue adding without pause
    Glue adding without pause

    Related Product

    Our perfect binding machine professionally handles everything from tender documents and books/albums to workbooks and daily receipt binding.

    Professional Straight-Line EVA Glue Binding Machine S10E S20E 16
    Book & Album Binding
    Ensures lay-flat functionality for art books & photographic collections
    Professional Straight-Line EVA Glue Binding Machine S10E S20E 17
    Workbook & Educational Material Binding
    Ideal for textbook & exercise book mass production
    Professional Straight-Line EVA Glue Binding Machine S10E S20E 18
    Receipt & Document Binding
    Securely binds financial documents & archival records
    glue binder applictaion (1)
    Tender Document Binding
    Professionally binds tender documents & proposals with clean, polished spines
    👉 Contact us now for a quote or more details!


    Not sure which model fits your needs? [Contact Us Today] for a free application analysis and personalized machine recommendation! Our specialists will help you choose the perfect binding solution for your specific requirements.

    Product parameters

    Product Specification
    Other attributes

    Key attributes

    Type Glue Binding Machine Power Electricity
    Place of Origin Henan,China Brand Name Prince
    Model Number Prince-S10e Length of gummed binding 110-320mm
    Glued binding thickness 1-58/55mm Core height 135-210mm(Manual 300)
    Manual maximum cover L660*W320mm Automatic maximum cover L490*W320mm
    Glued minimum cover L270*135mm Cover thickness 120-300mm
    Product name Glue Binding Machine Keyword Book Binding Machine Glue






    Packaging and delivery

    Selling Units Single item Single package size 200*200*100cm
    Single gross weight 500KG


    Model
    ZM-s10e
    ZM-s20e
    Length of gummed binding
    110-320mm
    110-320mm(Manual460)
    Glued binding thickness
    1-58/55mm
    1-58/55mm
    Core height
    135-210mm(Manual 300)
    135-210mm
    Manual maximum cover
    L660*W320mm
    L660*W460mm
    Automatic maximum cover
    L490*W320mm
    L660*W460mm
    Glued minimum cover
    L270*W135mm
    L270*W135mm
    Cover thickness g
    120-300mm
    120-300mm
    Cover stacking height
    88mm
    88mm
    Cover method
    Lifting upper suction
    Lifting upper suction
    Cover indentation
    CNC Rolling
    CNC Rolling
    Side Gauge
    CNC Rolling
    CNC Rolling
    Theoretical speed
    300-420books/h
    300-420books/h
    Melting time
    35min
    45min
    Book thickness automatic variable speed
    yes
    yes
    Gluing method
    3
    4
    Pre-soluble glue hopper replenishment
    yes
    yes
    Independent temperature control of laminating rollers
    no
    yes
    Adjustment of roller height
    yes
    yes
    Automatic side gluing of the glue take-up mechanism
    yes
    yes
    Milling knife
    High-speed milling cutters
    High-speed milling cutters
    Book handling platform
    yes
    yes
    Automatic book thickness measurement
    yes
    yes
