PRINCE P-850F 4 Color Flexo Printing Machine
120m/min Automatic Roll to Roll for Paper Plastic Non Woven Label
- Ultra-High Speed Printing: 0-120m/min stepless speed, 4-color simultaneous printing for high-efficiency bulk production.
- Multi-Material Compatibility: Prints on paper, plastic film, non-woven, aluminum foil, PVC and self-adhesive tape.
- Precision Color Registration: Real-time LCD screen monitoring + automatic deviation correction, zero color offset for sharp prints.
- Dual Drying System: 4 sets of infrared drying units, UV curing optional, fast ink drying without smudging.
- Intelligent Tension Control: Magnetic powder brake + constant tension system, no material deformation during printing.
- Industrial Grade Build: 4200kg sturdy structure, 1000mm max unwinding/rewinding diameter, 24/7 continuous working.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Description
Product Selling Points
Seamless LayFlat Technology
Product Details
Unwinding Unit
1000mm max roll diameter, hydraulic lifting structure for easy loading; 10KG magnetic powder brake + ultrasonic automatic deviation corrector, constant tension feeding without material misalignment.
Printing Unit
4-color stack structure with ceramic anilox rollers and 2.38mm thick printing plates; 360° circumferential plate alignment and individual unit engagement, flexible color combination for custom printing.
Color Registration System
Planetary gearbox regulator + real-time LCD screen monitoring with cruise photography, ±0.1mm precision color alignment, zero offset for complex patterns and brand logos.
Drying System
4 sets of independent infrared drying ovens with adjustable temperature; UV curing device optional for UV ink, fast ink drying (1-3s) to avoid smudging during rewinding.
Tension Control System
•Central constant tension controller, maintains consistent tension from unwinding to rewinding – suitable for thin and thick materials alike, no stretching or wrinkling.
Rewinding Unit
1000mm max friction rewinding diameter with air-expanding mandrel; back-to-back post-traction roller system, neat and tight winding of finished products, no loose rolls.
Have questions about machine customization, material compatibility or ink selection? 👉 Reach out to our sales experts – we’ll tailor a perfect one-stop flexo printing solution for you and deliver on time!
Application Range
Specific Usage Scenarios
How to Choose the Right Layflat Binding Machine
1
Q: What materials can this 4 color flexo printing machine process?
A: It prints on paper, plastic film, non-woven fabric, aluminum foil, PVC and self-adhesive tape – one machine for all your packaging and label printing needs.
2
Q: What is the maximum printing width and roll diameter of the machine?
A: Max printing width is 840mm, feed width 850mm; max unwinding/rewinding diameter is 1000mm with air-expanding mandrel for large roll loading.
3
Q: Does the machine support UV curing and infrared drying?
A: Yes, it is equipped with 4 sets of infrared drying units as standard, and UV curing device is optional for different ink types (water-based/UV ink).
4
Q: How many operators are needed to run this machine?
A: Only 1 person – the fully automatic workflow (hydraulic loading to auto rewinding) with one-key control requires no extra manual operation, just basic parameter setting.
5
Q: Does the machine have real-time color registration monitoring and automatic deviation correction?
A: Yes, it features LCD screen real-time color registration monitoring with cruise photography and ultrasonic automatic deviation correction – zero color offset for all printing jobs.
