PRINCE ZM-LS9-1300 Slitting Rewinding Machine
200m/min BOPP Film Paper Label Roll to Roll Slitting Machine
- Ultra-High Speed Production: 10-200m/min stepless speed regulation, meets bulk slitting demands for film/paper/label roll materials.
- High Precision Slitting: ±0.5mm cutting accuracy, straight knife structure, ensures consistent finished product specifications with no material waste.
- Wide Material Compatibility: Slits 20g-300g/㎡ paper, BOPP/PET/CPP/PVC film, non-woven fabric – one machine for multiple packaging/printing materials.
- Intelligent Deviation Correction: Photoelectric automatic deviation correction, magnetic powder brake tension control, avoids edge misalignment during slitting.
- Dual Shaft Rewinding: 3-inch air expansion shafts, max 500mm rewinding diameter, single/dual-shaft optional for tidy and tight roll winding.
- User-Friendly PLC Control: Rotatable touch screen, automatic metering & preset length stop, one-person operation with no professional training.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Description
Product Selling Points
Seamless LayFlat Technology
•200m/min Industry High Speed: 10-200m/min frequency conversion speed regulation, 4x faster than ordinary slitting machines, easily fulfills bulk roll material slitting orders for packaging factories.
•±0.5mm Precision Slitting: High-hardness straight knife structure with 8 sets of adjustable knife holders, consistent cutting for 20g-300g/㎡ materials, minimizes material waste to the greatest extent.
•Multi-Material Universal Compatibility: Slits kraft paper, coated paper, BOPP/PET/CPP/PVC plastic film and non-woven fabric – one machine replaces multiple special slitting equipment, saves investment cost.
•Intelligent Deviation & Tension Control: Photoelectric automatic deviation correction + magnetic powder brake constant tension control, avoids edge misalignment and material wrinkling, ensures perfect slitting effect.
•Dual Air Expansion Shaft Rewinding: 3-inch key-type air expansion shafts for unwinding/rewinding, one-key inflation/locking, max 500mm rewinding diameter, tidy finished roll end face with no loose winding.
•Humanized PLC Intelligent Control: Rotatable touch screen with automatic metering, alarm and preset length stop functions, real-time production monitoring, one-person operation saves 80% labor cost.
•Flexible Knife Adjustment: 8 sets of quick-adjust knife holders, free customization of slitting width, adapts to diverse production needs of different specifications of roll materials.
Product Details
Unwinding Unit
Max 600mm unwinding diameter, magnetic powder brake for precise constant tension control, avoids material breakage and deviation, matches various roll material hardness and thickness.
Traction & Guiding Device
Multi-group driving and guiding rollers, smooth material transmission with no slipping, ensures stable slitting speed and consistent cutting precision.
Slitting Device
High-hardness straight knife structure with 8 adjustable knife holders, quick knife position adjustment for different slitting widths, burr-free cutting for paper and film materials.
Rewinding Section
Dual 3-inch air expansion shafts, single/dual-shaft rewinding optional, max 500mm rewinding diameter, matching pressure rollers ensure tidy and tight finished roll end face.
Deviation Correction System
•Photoelectric deviation correction sensor with ±0.5mm correction precision, automatically adjusts material position, avoids edge misalignment and uneven slitting.
PLC Control System
•Rotatable color touch screen, frequency conversion speed regulation, automatic metering, preset length stop and fault alarm, one-key parameter setting for easy operation.
Ready to upgrade your roll material processing with a 200m/min high-precision slitting rewinding machine? Contact us today for a free custom quote and machine video demo – exclusive bulk discounts for packaging and printing factory partners!
Application Range
•Packaging Industry: Slitting of BOPP/PET/CPP food packaging film, daily chemical product packaging film and gift box composite packaging material rolls.
•Printing Industry: Edge trimming and slitting of printed roll paper, label base material, flexible packaging printing substrate and adhesive label rolls.
•Plastic Processing Industry: Slitting of PVC/CPE plastic film, plastic packaging roll material and plastic composite film for various plastic products processing.
•Paper Product Industry: Slitting of kraft paper, coated paper and composite paper rolls for subsequent paper bag, carton and paper box making production.
•Textile & Non-Woven Industry: Slitting of non-woven fabric rolls, textile packaging materials and non-woven shopping bag base material rolls.
Specific Usage Scenarios
How to Choose the Right Layflat Binding Machine
1
Q: What materials and thickness/grammage can this slitting rewinding machine process?
A: It slits 20g-300g/㎡ paper (kraft/coated), BOPP/PET/CPP/PVC plastic film and non-woven fabric, adapting to most packaging and printing roll materials.
2
Q: What is the maximum slitting width and rewinding diameter of the machine?
A: Max raw material width is 1300mm, max rewinding diameter of finished products is 500mm, with 3-inch air expansion shafts for unwinding and rewinding.
3
Q: What is the slitting precision and speed range of the machine?
A: Cutting precision is ±0.5mm, speed is adjustable from 10-200m/min via frequency conversion, matching different production efficiency requirements.
4
Q: Does the machine have automatic deviation correction and tension control functions?
A: Yes, it is equipped with photoelectric automatic deviation correction (±0.5mm precision) and magnetic powder brake constant tension control, avoiding material misalignment and wrinkling.
5
Q: Can the machine realize single or dual-shaft rewinding, and is the knife position adjustable?
A: Yes, dual 3-inch air expansion shafts support single/dual-shaft optional rewinding; 8 sets of knife holders enable quick knife position adjustment for different slitting widths.
