High Speed Automatic Thermal Paper Roll Cutting Machinery Thermal Paper Roll Slitting and Rewinding Machine

Model: ZM-GW-FQ-900

MOQ: 1

Delivery time: 30-60 days

Start Port: Guangzhou,Ningbo,Shenzhen ect,.

Certification: CE,IOS,RUSH ect,.

Brand: Prince

Factory Price: Negotiate

Supply Ability: 1000 Set/Sets per Month

Payment Terms: L/C, Cash,T/T,Western Union ,Trade Assurance, Paypal

ODM & OEM: Available



Scope of suppl:

One main engine
Unwind air shaft  1 pc
Top cutter 5 pieces (in the tool box)
Down cutter 5 pieces (in the tool box)
Rewind shaft    Ø12 mm, Ø 15 mm, Ø 17 mm 2 pieces of each
One set of flattening device
Programmable controller MIKOM   1 pc
One inverter MIKOM
One touch screen MIKOM
Tension controller WENNEW   1pc

    oops...!

    no product data.

    Go to homepage

    Product parameters

    Product Specification
    Other attributes

    Product Name

    OR-1000VA

    Max.Cutting Size

    340*300mm

    Min.Cutting Size

    80*80mm

    Max.Cutting Height

    60mm

    Min.Cutting Book Height

    10mm

    Min.Single Cutting Height

    5mm

    Cutting Speed

    1100 times/H

    Power

    4KW

    Overall Dimension

    L1520*W1820* H1680mm

    Machine Weight

    1700kg

    Model

    ZM-GW-FQ-900

    Max. Jumbo Roll Width

    860mm

    Max. Jumbo Roll Dia.

    1000mm

    Max. Rewinding Dia.

    150mm

    Max. Unwinding Speed

    150m/min

    Unwinding Shaft

    3” Pneumatic Air Expanding Shaft

    Weight

    1000kg

    Voltage

    3 Phase 380V 50HZ

    Rewinding Shaft in Diameter

    0.5'',1 inch ,Coreless(8mm)

    Overall Dimensions

    2050*1600*1500mm

    Product Description

    Thermal paper slitting machine is mainly applied for slitting thermal paper, fax paper, cash register paper, carbon-less paper,and other kinds of paper grammage that less than 250gsm. It equips PLC +touch screen control, automatic tension control, automatic product separation, automatic counting, automatic pneumatic loading system, which make it easy to operate by only one worker. Its features are high speed and stability, high precision, and long working life. The defective rate is only 3‰.It brings much more profit to clients than before. It is the most ideal slitting machine for small size paper roll producing.

    热敏纸分切机_01

    Product Features

    热敏纸分切机_03
    Thermal Paper Machinery Equipped with Panasonic PLC and touch screen, all the parameter are displayed on the monitor. You only need to setup the material roll diameter and thickness, the PLC will give a proper parameters for machine running automatically.
    热敏纸分切机_03
    Thermal Paper Roll Slitting Machine
    Thermal Paper Roll Slitting Machine Equipped with Auto Tension Control System for unwinding tension. With meter counter. Got to the setup data, the machine stops and alarms.
    热敏纸分切机_04
    热敏纸分切机_04
    All the electric appliances has been gained the CE certificate.
    热敏纸分切机_04
    热敏纸分切机_04
    Thermal Paper Roll Slitting and Rewinding Machine adopts frequency inverter for main inverter motor driving, the speed can be displayed on the operation panel. Frequency inverter motor: 2.2Kw.
    热敏纸分切机_04
    热敏纸分切机_04
    All transmission rollers have been dynamic/static balance treated. Equipped with emergency switch.

    more  Details

    热敏纸分切机_01
    01
    Thermal Paper Machinery Equipped with Panasonic PLC and touch screen, all the parameter are displayed on the monitor. You only need to setup the material roll diameter and thickness, the PLC will give a proper parameters for machine running automatically.
    热敏纸分切机_05
    02
    Thermal Paper Roll Slitting Machine Equipped with Auto Tension Control System for unwinding tension. With meter counter. Got to the setup data, the machine stops and alarms.
    热敏纸分切机_03
    03
    All the electric appliances has been gained the CE certificate.
    热敏纸分切机_04
    04
    Thermal Paper Roll Slitting and Rewinding Machine adopts frequency inverter for main inverter motor driving, the speed can be displayed on the operation panel. Frequency inverter motor: 2.2Kw.
    热敏纸分切机_02
    05
    All transmission rollers have been dynamic/static balance treated. Equipped with emergency switch.

    Product Show

    热敏纸分切机_05
    热敏纸分切机_05
    热敏纸分切机_05
    热敏纸分切机_05

    Applicable

    热敏纸分切机_06
    热敏纸分切机_06
    热敏纸分切机_06
    热敏纸分切机_06


    A thermal paper slitter, also known as a thermal paper rewinder or a thermal paper cutting machine, is specifically designed for the precise and efficient cutting of thermal paper into smaller rolls. Here are some typical use cases and applications for a thermal paper slitter:


    1. Retail and Point of Sale (POS) Systems:
    •Application: Producing rolls of thermal paper for cash register receipts, credit card slips, and POS terminals.
    •Benefits: Ensures consistent quality and size for smooth operation in POS printers.

    2. Automated Teller Machines (ATMs):
    •Application: Cutting thermal paper for ATM transaction receipts.
    •Benefits: Reliable and precise cutting to match the specific requirements of ATM printers.

    3. Medical and Healthcare Settings:
    •Application: Creating rolls of thermal paper for medical record keeping, patient charts, and diagnostic equipment like ECG machines.
    •Benefits: High-quality printing for clear and legible records.


    4. Faxes and Communication Devices:
    •Application: Producing thermal fax paper rolls.
    •Benefits: Efficient production of fax paper rolls that meet the size and quality standards for clear transmission.

    5. Printing and Office Supplies:
    •Application: Manufacturing rolls of thermal paper for office printers, including label printers and ticket printers.
    •Benefits: Customizable roll sizes and lengths to fit various printer models.


    6. Logistics and Shipping:
    •Application: Producing rolls of thermal paper for shipping labels, waybills, and tracking documents.
    •Benefits: Precise cutting and consistent quality for accurate and durable labels.


    7. Gaming and Entertainment:
    •Application: Cutting rolls of thermal paper for lottery tickets, gaming machines, and amusement park receipts.
    •Benefits: Fast and efficient production to meet high-volume demands.


    8. Manufacturing and Production Lines:
    •Application: Cutting thermal paper for production line tracking, inventory management, and quality control documentation.
    •Benefits: Streamlined production processes and improved traceability.


    9. Service Industries:

    •Application: Producing thermal paper for restaurant orders, hotel bills, and airline boarding passes.
    •Benefits: Quick and easy production of high-quality prints for customer-facing documents.


    10. Custom Applications:
    •Application: Customizing thermal paper rolls for specific industries or niche applications.
    •Benefits: Tailored solutions that meet unique requirements, such as specialized coatings or unusual sizes.
