Color Adhesive Roll Label Rotary Laminating Die Cutting Slitting Rewinding Machine Digital Bottle Label Sticker Printing Machine

The digital label cutting machine VR330LP is an all-in-one label finisher, with multiple functions including printing, laminating, die cutting, slitting and rewinding, provides the perfect solution for small batch label production.

Model ：VR-330LP

MOQ ：1

Delivery time：30-60 days

Start Port ：Guangzhou,Ningbo,Shenzhen ect,.

Certification ：CE,IOS,RUSH ect,.

Brand：Prince

Factory Price：Negotiate

Supply Ability：1000 Set/Sets per Month

Payment Terms：L/C, Cash,T/T,Western Union ,Trade Assurance, Paypal

ODM & OEM：Available

Inquiry

Write a Review

Product parameters

Product Specification

Other attributes

Type

Label Printer

printing head

other

place of origin

Henan, China

brand name

allraise

condition

New

dimensions(l*w*h)

1660*615*1194mm

plate type

Flatbed Printer

weight

269

automatic grade

Automatic

usage

Card Printer, Bill Printer, Label Printer

voltage

220v 50hz

warranty

1 Year

Product name

Roll-to-roll Digital Label Machine

Max. label width

210mm

Min. label width

100mm

Speed

10-700mm/s

Max. unwinding roll diameter

500mm

Max. laminating roll diameter

300mm

Max.winding roll diameter

300mm

Power

100-120V, 200-240V, 50/60Hz

Machine size

1660(L)x615(W)x1194(H)mm

Selling Units:

Single item

Machine Specifications
Model	VR-330LP
Max. label width	210mm
Min. label width	100mm
Speed	10-700mm/s
Max. unwinding roll diameter	500mm
Max. laminating roll diameter	300mm
Max.winding roll diameter	300mm
Max. matrix removing roll diameter	300mm
Cutting precision	0.02mm
Power	100-120V, 200-240V, 50/60Hz
Machine size	1660(L)x615(W)x1194(H)mm
Weight	268.6kgs

Product Description

The camera scan the marks on the printed media to positioning the cutting images accurately, very complex contours can also be made and applied to advertising, display, packaging, color printing and many other industries.

With automatic waste winding system the waste can be wound on the waste paper rod alone, delivers clean finished labels.

More Details

xiangqingtu (1)

A combination of printing, die cutting, laminating, slitting, web matrix, rewinding, each part works coordinated, stable and orderly.

xiangqingtu (1) (2)

Users can choose E-pson printer to be integrated into the machine to realize printing and cutting linkage. The dedicated control software can run both printing and cutting, to provide one-stop label finishing solution.

xiangqingtu (3)

After printing, laminating first and then die cut, makes finishing labels more durable and more widely application. The machine adopts cold laminating method, there is a buffer beside of laminating roller, which can release the tension of films to reduce the noise during laminating.

xiangqingtu (4)

The mainframe of die-cutting adopts the structure of classical plotter. Servo drive guarantee fast moving speed on scanning marks and cutting contours.

xiangqingtu (2)

The camera scans the mark points on the printing medium and feeds back to the control center, so as to realize accurate contour cutting. The whole process is visible through the screen.

xiangqingtu (5)

Under the tension of the waste discharge system, the label cutting waste paper will be automatically removed and separated from the winding, so as to obtain a clean label roll for the next proces

Product Show

4 (58)

Production Process

02 (3)

With dedicated control software, it integrates printing and cutting to realize the in-line production, and truly provides a one-stop solution for label, making it an ideal flexible digital label finisher for large production plants as well as small and medium-sized companies.

VR330LP roll label finisher is mainly used in producing wide range of labels including blank labels, ink labels, chemical labels, beverage labels, bottled water labels, chili source labels, coffee labels, cosmetic labels, home appliance label, toiletries label, gum label, wine labels and more.
