To build a complete rigid box production line, we strongly recommend pairing this OR950 cardboard V groove cutting machine with our related products below:
OR900A/950A Full Automatic Cardboard V Groove Cutting Machine
Gray Cardboard Slotting Machine Cardboard V Grooving Machine
- Fully automatic cardboard V groove cutting machine – The OR950 is a high-precision paperboard grooving machine designed for creating precise V-shaped grooves on greyboard, industrial paperboard, MDF, and cardboard for rigid box production.
- High production speed – Operating speed up to 35-36 m/min. Handles paperboard width 100-850mm, length 90-500mm. Significantly improves productivity over manual methods.
- Ultra-high precision – Achieves ±0.1mm cutting precision for flawless, consistent V-grooves. Ensures clean folds and professional box finishing.
- Belt feeding system – Automatic belt feeding with single-side conveying ensures stable and accurate paperboard positioning. Eliminates inconsistencies of manual feeding.
- Wide material compatibility – Processes greyboard, industrial paperboard, MDF, and cardboard. Paper thickness up to .
- Automatic product collection – Final products are automatically collected, reducing manual labor and increasing efficiency.
- Durable construction – Machine weight 1600kg. Dimensions 2100×1400×1350mm. Built with high-quality components for demanding industrial environments.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Description
This fully automatic machine is the new products we have developed according to market, it is the system equipment in cardboard boxes slitting equipment, it is the high performance, easy to operate, convenient adjust, working stable and reliable, paper feeding and slitting into one of the automation equipment, it is the preceding equipment in the process of the gift box packaging. This machine is mainly used for make V and U type groove on ash cardboard, copperplate paper, glossy paper,mounted cardboard,paper board and MDF board etc.
V Groove Cutting Machine Product parameters
Product Specification
Other attributes
|
Model |
OR-950 |
|
Width Of Cardboard |
100-850mm |
|
Length Of Cardboard |
90-500mm |
|
Cardboard thickness |
300gsm-3mm |
|
Grooving Degree |
80-140 degree (adjustable) |
|
The amount of Groove |
8 slots |
|
Normal Speed |
20-25 m/min |
|
Fastest Speed |
35-36 m/min |
|
General power |
3kw |
|
Weight |
1600kg |
|
Dimension |
2100*1400*1350mm |
|
Video outgoing-nspection |
Provided |
Machinery Test Report |
Provided |
|
Applicable Industries |
Hotels，Garment Shops,Builing material Shops |
Warranty of core components |
1 years |
|
Core Components |
Hard Cover Book Machine |
Place of Origin |
Henan, China |
|
Weight |
1480 KG |
Core Components |
Motor |
|
Key Selling Points |
Easy to Operate |
Condition |
New |
|
Automatic Grade |
Automatic |
Brand Name |
PRINCE |
|
Voltage |
220V/380V |
Dimension(L*W*H) |
2100*1400*1350mm |
|
Power |
3.0KW |
Application |
Food,Beverage,Commodity,Chemical |
|
Driven Type |
Electric |
Keyword |
Box Grooving Machine |
|
Function |
Box Production |
Application |
Box Forming Company |
|
Speed |
120pcs/min |
Application area |
Paper Box Products Line |
|
Packing |
Wooden Case |
Port |
Any main port in China |
Cardboard V Groove Cutting Machine Product Selling Points
Cardboard V Groove Cutting Machine Product Selling Points
- Full-automatic operation design: Full auto functions: auto feeding, collecting, deviation correction and chip removal, less labor input.
- Complete accessory configuration: Complete standard spare parts: correction belt, feed belt, roller belt, V cutter, plus a 1m-height conveyor.
- Labor-saving lubrication structure: Centralized oil lubrication system, fast, easy and stable blade adjustment, prolong service life of cutters.
- High precision grooving technology: Rotary knife grooving technology, quick blade setting, clean burr-free V-grooves for rigid boxes.
- Stable industrial production performance: Computer optimized structure, high precision, stable low-noise operation, 24h continuous production without mechanical impact.
Product Details
Internal Power Supply & Wiring Terminals
- Compatible with global factory voltage standards;
- Separated wires for easy maintenance and part replacement;
- Locked terminals prevent loose wires, single-circuit maintenance without full machine shutdown.
Integrated Electric Control Cabinet
- PLC fully automates feeding, grooving and collecting procedures.
- Frequency converter provides 0~36m/min stepless speed for all boards.
- Auto stop & alarm for overload, jam and short circuit to protect machine.
Auto Feeding & Deviation Correction Conveyor
- Adjustable baffles fit 120-900mm boards, auto correct offset to avoid wrong groove position;
- Top pressing cover stops boards from warping or jumping, anti-slip conveying;
- Works for gift boxes, jewelry boxes, moon cake boxes, book covers and all packaging boards.
Rotary V-Groove Cutter Processing Station
- Rotary cutter creates burr-free even V-grooves for neat box folding;
- Up to 9 grooves per pass, handwheels quickly adjust for different box types;
- Automatic scrap discharge avoids board surface scratches;
- Metal safety guard isolates high-speed cutters, complies with CE industrial safety standards.
Product Show
cardboard grooving machine
rigid box grooving machine
Application Range
- Rigid box manufacturers – Produce rigid gift boxes, presentation boxes, and premium packaging. V-grooves enable sharp, clean folds.
- Gift and luxury packaging companies – Manufacture moon cake boxes, wine boxes, jewelry boxes, and cosmetic boxes.
- Electronics packaging factories – Produce rigid boxes for smartphones, tablets, and electronic devices.
- Bookbinding and publishing – Create book covers, hardcover journals, and premium stationery.
Specific Usage Scenarios
cardboard v groove cutting machine
- Gift boxes – V-grooves enable precise folding of rigid gift boxes with clean, sharp edges.
- Moon cake boxes – Premium packaging for moon cakes and holiday gifts.
- Wine boxes – Sturdy rigid boxes for wine bottles and gift sets.
- Jewelry boxes – Elegant rigid boxes for rings, necklaces, and watches.
- Mobile phone boxes – Rigid packaging for smartphones and electronics.
- Book covers – Hard covers for books, journals, and photo albums.
- Cosmetic boxes – Premium packaging for perfume, skincare, and makeup products.
- Shoe boxes – Sturdy rigid boxes for footwear and accessories.
1
What is a cardboard V groove cutting machine?
A cardboard V groove cutting machine, also known as a V-grooving machine, creates precise V-shaped grooves on paperboard, greyboard, and cardboard to enable clean, sharp folding for rigid box production.
2
What materials can this automatic V grooving machine process?
Greyboard, industrial paperboard, MDF, cardboard, and other rigid paper materials.
3
What is the cutting precision of this cardboard V groove cutting machine?
±0.1mm maximum precision.
4
What is the cardboard V groove cutting machine price?
The price varies by configuration. Contact us now for a detailed quotation based on your specific requirements.
5
How do you ship the finished products?
By Sea, By Plane, By courier, TNT , DHL, Fedex, UPS Etc.
